AP322GR-EC-LTE-LORAWAN-EU433

    3,242.59 3,242.59 3242.59 USD

    3,242.59

    This combination does not exist.

    Add to Cart
    Related Documents:

    Industrial LoRaWAN Gateway, 2GbE+2COM, LTE 2SIM, FDD B1/3/7/8/20/28A, LoRaWAN EU433: 433.05~434.79MHz (with LTE and LoRa antennas)(Must work with AP140-LR)


    Terms and Conditions
    30-day money-back guarantee
    Shipping: 2-3 Business Days

    The AP322GR-EC-LTE-LoRaWAN is a programmable cellular or Ethernet gateway for  LoRaWAN communication. The Semtech S1301 supports the LoRAWAN protocol for  long-range wireless connection to multiple LoRaWAN nodes. The AP322GR-EC-LTE-LoRaWAN gateway converts LoRaWAN™ data to MQTT and transmits to the cloud  through the LTE network. The gateway comes with two software-selectable RS-232/422/485 Modbus full-signal serial ports and two 10/100/1000 Mbps Ethernet ports. The built-in Node-RED flow-based programming in the gateway provides a reliable and  secure gateway for data acquisition and processing at field sites as well as a user-  friendly communication platform for many other large-scale deployments. Combining  with the new LoRaWAN controller AP140-LR, Cloud platform ATMS, and various  environmental sensors, AVCOMM presents complete IoT Environment Monitoring  applications.


    Product Features:
    Programmable Edge Computer and  Gateway

    QCA9558 MIPS-based processor 720MHz  processor

    2 auto-sensing 10/100/1000 Mbps Ethernet ports

    SD socket for storage expansion

    Rich programmable LEDs and a programmable  button for easy installation and maintenance

    Node-RED flow-based programming

    High speed 4G LTE

    LTE Cat.4, 2x2 MIMO, 150M downlink and 50M  uplink

    LTE Cat.6 with 2CA, 2T2R MIMO provides 300M  downlink and 50M uplink

    4G/3G/2G full cellular network compatibility

    Support GPS for location services

    Serial Communication & High Throughput  Data Switching

    Dual serial ports with RS232/422/485 full functions for  serial over LTE/Wi-Fi/Ethernet data switching

    2-port Gigabit Ethernet supports routing and bridging mode

    Hardware NAT for CPU utilization saving*

    Cloud Management Service

    Support Amazon AWS & Microsoft Azure cloud service*

    Support proprietary ATMS cloud service*

    Interactive monitoring dashboard and map shows the  status, signal strength, location etc.*
